MSI MPG Z390I Gaming Edge AC LGA1151 (Intel 8th and 9th Gen) M.2 USB 3.1 Gen 2 DDR4 HDMI DP Wi-Fi Mini ITX Z390 Gaming Motherboard

MSI

● Supports 9th i9-9900K, i7-9700K, i5-9600K and 8th Generation Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket
● Supports dual channel DDR4 Memory, up to 4600(OC) MHz
● 2x TURBO M.2, Intel Optane Memory Ready. Turbo USB 3.1 GEN2
● AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
● Built for high-performance small-form factor builds – Extended heatsink, mini-ITX form factor


Availability:

Request a Quote: quotes@buyandsave.co.za

R6,047.49 Inc. VAT

Request a Quote: quotes@buyandsave.co.za



From the manufacturer

Intel Z390 Motherboard Intel Z390 Motherboard
Intel Wi-Fi 1.73G Intel Wi-Fi 1.73G

Intel Wi-Fi 1.73G

Included Intel Wi-Fi / Bluetooth solution uses smart MU-MIMO technology, delivering AC speeds up to 1.73Gbps.

Twin Turbo M.2 Twin Turbo M.2

Twin Turbo M.2

Enjoy a blazing fast system boot up, quick applications load times, and high data transfer with MPG Z390I GAMING EDGE AC. Two M.2 slots each can deliver speeds up to 32Gb/s for NVMe SSDs.

Intel Turbo USB 3.1 Gen2 Intel Turbo USB 3.1 Gen2

Intel Turbo USB 3.1 Gen2

Powered by an Intel USB 3.1 Gen2 controller, MPG Z390I GAMING EDGE AC can quickly transfer games, music and videos over USB 3.1.

Audio Boost Audio Boost

Audio Boost

Audio Boost offers a HD audio processor and high quality sound components, all physically isolated from the rest of the motherboard circuitry for immersive audio.

Core Boost Core Boost

Core Boost

Core Boost technology combines MSI’s premium circuit layout and digital power design to deliver undistorted current to the CPU with pin-point precision.

Become an MSI Dragon Fan and Get Rewarded Become an MSI Dragon Fan and Get Rewarded

Become an MSI Dragon Fan and Get Rewarded

MSI is keen to hear from you! Share your product experience and get rewarded. Your feedback is appreciated. Become an MSI Dragon Fan today!

Visit MSI US website for more information on rewards.

Intel Z390 Motherboard Intel Z390 Motherboard

Compare Items

MPG Z390 GAMING PLUS

MPG Z390 GAMING PLUS

MPG Z390M GAMING EDGE AC

MPG Z390M GAMING EDGE AC

MPG Z390I GAMING EDGE AC

MPG Z390I GAMING EDGE AC

Z390-A PRO

Z390-A PRO

Intel 9th/8th Gen CPU Support
Intel Core/Pentium/Celeron Intel Core/Pentium/Celeron Intel Core/Pentium/Celeron Intel Core/Pentium/Celeron
Chipset
Intel Z390 Chipset Intel Z390 Chipset Intel Z390 Chipset Intel Z390 Chipset
Graphics Interface
2 x PCIe 3.0 x 16 slots 2 x PCIe 3.0 x 16 slots 1 x PCI-E 3.0 x 16 slot 2 x PCIe 3.0 x 16 slots
Display Interface
HDMI / DVI-D DisplayPort / HDMI DisplayPort / HDMI DisplayPort/VGA/DVI-D
Memory Support
4 DIMMs, Dual Channel DDR4 4 DIMMs, Dual Channel DDR4 4 DIMMs, Dual Channel DDR4 4 DIMMs, Dual Channel DDR4
Expansion Slots
4 x PCIe 3.0 x 1 slots 2 x PCIe 3.0 x 1 slots 4 x PCIe x 1 slots
M.2 / SATA
2 x M.2 32Gb/s; 6 x SATA 6Gb/s 2 x M.2 32Gb/s; 6 x SATA 6Gb/s 2 x M.2 32Gb/s; 6 x SATA 6Gb/s 1 x M.2 32Gb/s; 6 x SATA 6Gb/s
SATA RAID
RAID 0, 1, 5, 10; SATA1-SATA6 RAID 0, 1, 5, 10; SATA1-SATA6 RAID 0, 1, 5, 10; SATA1-SATA6 RAID 0, 1, 5, 10; SATA1-SATA6
LAN
Intel I219-V Gigabit LAN Intel I219-V Gigabit LAN Realtek 8111H Gigabit LAN Intel I219-V Gigabit LAN
Audio
8-Channel (7.1) HD Audio 8-Channel (7.1) HD Audio 8-Channel (7.1) HD Audio 8-Channel (7.1) HD Audio
Wi-Fi / BT
Intel Wireless-AC 9560 Intel Wireless-AC 9462
Form Factor
ATX Micro-ATX Mini-ITX ATX
