From the manufacturer

$\"Intel$ $\"Intel$

$\"Mystic$ $\"Mystic$

Mystic Light

Personalize your PC with 16.8 million colors and 29 effects through with the Mystic Light App or a mobile device.

$\"Audio$ $\"Audio$

Audio Boost 4 with Nahimic 3

Isolated audio circuitry, a high quality ALC1220 audio processor, dedicated amplifier, and high quality audio capacitors delivery immersive sound.

$\"M.2$ $\"M.2$

M.2 Shield Frozr

Fast SSDs can slow down when they get too hot. M.2 SHIELD FROZR extends the motherboard’s heatsink over an M.2 SSD to prevent thermal throttling and sustain maximum drive performance.

$\"Front$ $\"Front$

Front USB 3.1 Gen2 Type-C

Powered by an Intel USB 3.1 Gen2 controller, MPG Z390 Gaming Pro Carbon AC supports dual front USB 3.1 Gen2 Type-C for computer cases.

$\"Pre-installed$ $\"Pre-installed$

Pre-installed I/O Shielding

Make the assembly process easier and safer with MPG Z390 Gaming Pro Carbon AC. The pre-installed rear I/O is grounded and protects the I/O ports from potential electrostatic discharge damage from the external environment.

$\"Become$ $\"Become$

Become an MSI Dragon Fan and Get Rewarded

MSI is keen to hear from you! Share your product experience and get rewarded. Your feedback is appreciated. Become an MSI Dragon Fan today!

Visit MSI US website for more information on rewards.

$\"Intel$ $\"Intel$

Compare Items

	$\"MEG$ MEG Z390 Godlike	$\"MEG$ MEG Z390 ACE	$\"Z390$ Z390 Gaming Pro Carbon AC	$\"Z390$ Z390 Gaming Pro Carbon	$\"MPG$ MPG Z390 Game Edge AC	$\"MAG$ MAG Z390 TOMAHAWK
Intel 9th/8th Gen CPU Support	Intel Core/Pentium/Celeron	Intel Core/Pentium/Celeron	Intel Core/Pentium/Celeron	Intel Core/Pentium/Celeron	Intel Core/Pentium/Celeron	Intel Core/Pentium/Celeron
Chipset	Intel Z390 Chipset	Intel Z390 Chipset	Intel Z390 Chipset	Intel Z390 Chipset	Intel Z390 Chipset	Intel Z390 Chipset
Graphics Interface	4x PCIe 3.0 x 16 slots	3 x PCI-E 3.0 x 16 slots	3 x PCI-E 3.0 x 16 slots	3 x PCI-E 3.0 x 16 slots	3 x PCI-E 3.0 x 16 slots	3 x PCI-E 3.0 x 16 slots
Display Interface	—	—	DisplayPort / HDMI	DisplayPort / HDMI	DisplayPort / HDMI	DisplayPort / HDMI
Memory Support	4 DIMMs, Dual Channel DDR4	4 DIMMs, Dual Channel DDR4	4 DIMMs, Dual Channel DDR4	4 DIMMs, Dual Channel DDR4	4 DIMMs, Dual Channel DDR4	4 DIMMs, Dual Channel DDR4
Expansion Slots	1 x PCIe x 1 slots	3 x PCIe 3.0 x 1 slots	3 x PCIe 3.0 x 1 slots	3 x PCIe 3.0 x 1 slots	3 x PCIe 3.0 x 1 slots	2 x PCI-E 3.0 x1 slots
M.2 / SATA	3x M.2 32Gb/s; 6x SATA 6Gb/s	3x M.2 32Gb/s; 6x SATA 6Gb/s	2 x M.2 32Gb/s; 6 x SATA 6Gb/s	2 x M.2 32Gb/s; 6 x SATA 6Gb/s	2 x M.2 32Gb/s; 6 x SATA 6Gb/s	2 x M.2 32Gb/s; 6 x SATA 6Gb/s
SATA RAID	RAID 0, 1, 5, 10; SATA1-SATA6	RAID 0, 1, 5, 10; SATA1-SATA6	RAID 0, 1, 5, 10; SATA1-SATA6	RAID 0, 1, 5, 10; SATA1-SATA6	RAID 0, 1, 5, 10; SATA1-SATA6	RAID 0, 1, 5, 10; SATA1-SATA6
LAN	2 x Killer E2500 Gigabit LAN	Killer E2500 Gigabit LAN	Intel I219-V Gigabit LAN	Intel I219-V Gigabit LAN	Intel I219-V Gigabit LAN	Intel I219-V Gigabit LAN
Audio	8-Channel (7.1) HD Audio	8-Channel (7.1) HD Audio	8-Channel (7.1) HD Audio	8-Channel (7.1) HD Audio	8-Channel (7.1) HD Audio	8-Channel (7.1) HD Audio
Wi-Fi / BT	Killer Wi-Fi AC 1550	Intel Wireless-AC 9560	Intel Wireless-AC 9560	—	Intel Wireless-AC 9462	—
Form Factor	E-ATX	ATX	ATX	ATX	ATX	ATX
